FSII-SPL

$0.00

FreeSpeak II Transceiver Splitter

  • Provides 5 FSII transceiver feeds on one port on FSII base station or E-QUE-HX card
  • SFP fiber slot for fiber link to FSII base station or as a fiber bridge between FSII-BASE-II stations and Eclipse HX frames
  • Supports both multi-mode and single-mode fiber
  • Configure settings using DIP switches
  • IP-63 water resistance for outdoor use
  • LED status indicator on front and back
  • Mic stand or wall mount orientation (metric and imperial threads)
Add to wishlist
Compare
Categories: , ,

Description

FSII-SPL

  • FreeSpeak II Transceiver Splitter
  • Provides 5 FSII transceiver feeds on one port on FSII base station or E-QUE-HX card
  • SFP fiber slot for fiber link to FSII base station or as a fiber bridge between FSII-BASE-II stations and Eclipse HX frames
  • Supports both multi-mode and single-mode fiber
  • Configure settings using DIP switches
  • IP-63 water resistance for outdoor use
  • LED status indicator on front and back
  • Mic stand or wall mount orientation (metric and imperial threads)
Item Part Number:
  • FSII-SPL
  • Optional: HLI-MMFO multi-mode fiber SFP transceiver
  • Optional: HLI-SMFO single-mode SFP transceiver

Specifications

Technical Specifications

Connections

Transceiver Antenna: 5 Ethercon RJ-45, each with yellow LED indicators on front and back

Matrix: 1 Ethercon RJ-45, with yellow LED indicator on front and back

Fiber: 1 SFP port


Power

Splitter: Requires external power supply (included)

Transceiver Module: Provides power to modules via RJ-45 connections


Mounting Options

Wall Mount with 4 mounting points

Mic Stand Mount (metric and imperial threads)


Environmental

IP-63 water resistance for outdoor use

+32°F to +122°F

(0°C to +50°C)


Dimensions

1.65 x 8.75 x 7.73 in (HxWxD)

(42 x 223 x 197 mm)

Weight

24.5 oz (0.69 kg)
